Converter （Rasprobo 2）
$29.20
In stockUC-01 is a TTL/USB debugging adapter that supports both half-duplex and full-duplex communication, with switchable voltage levels between 3.3V and 5.0V.
Equipped with a Type-C interface, it is designed for configuring IDs, setting parameters, and enabling communication between bus servos, PCs, and other platforms—offering broad compatibility and ease of use.
Related Products
Main Horn (For 100kg Servos)
$50.00
Converter （PTC-32）
$22.60
TTL/RS232 Converter (UC-02)
$15.50
Overview
Direct Raspberry Pi Compatibility
Directly compatible with Raspberry Pi, with no additional wiring required.
UART Servo Interface
Integrated UART serial bus servo interface.
Servo Signal Conversion
Integrated full-duplex/half-duplex servo signal conversion.
USB/TTL Conversion
Integrated USB/TTL conversion with support for UART servo configuration software.
Air Pump and Solenoid Control
Integrated air pump and solenoid valve control circuitry, convenient for robotic arm design.
Inertial Navigation Module
Integrated inertial navigation module (IMU).
Self-Balancing Support
Supports robot self-balancing and advanced attitude algorithms.
Integrated Power Management
Integrated power management, capable of powering the Raspberry Pi directly.
Camera Fill Light Control
Integrated camera fill light control (GPIO4).
Multiple Expansion Interfaces
Integrated three interface types: I2C, digital, and button.
Low-Voltage Alarm
Supports low-voltage alarm.
Specification
|
Item |
Value |
|---|---|
|
Power Input |
6.0–8.4 V |
|
Power Switch |
Power ON/OFF |
|
I2C Interface |
Raspberry Pi breakout interface, compatible with the Grove interface definition |
|
5.0V Expansion Port |
Raspberry Pi breakout interface, compatible with the Grove interface definition |
|
3.3V Expansion Port |
Raspberry Pi breakout interface, compatible with the Grove interface definition |
|
Fill Light Interface |
Integrated fill light control circuitry for camera illumination |
|
Servo Interface |
CH1-CH6, for connecting UART serial bus servo |
|
Function Button |
Extended button with customizable functions |
|
Inertial Navigation Module |
IMU (MPU6050), supports robot self-balancing and advanced attitude algorithms |
|
Micro USB |
Connects to a PC for configuration and control via PC configuration software |
|
SW Interface |
Connects to a solenoid valve |
|
MT Interface |
Connects to an air pump motor |
|
Buzzer |
Low-voltage alarm |
|
Power Indicator |
Steady on after power-up |
|
Status Indicator |
Steady on when voltage is normal; blinking when voltage is low |
Interface Definition
CAD Drawing
No separate CAD drawing is provided on the official Wiki page.
Schematic
| Signal conversion | Half-duplex to full-duplex conversion |
|---|---|
| TTL level | 3.3v, 5.0v |
| Peak Current | 20A |
| UART output | 1 |
| Data interface | Type-C |
| Operating Temperature | -10 ~ 60 °C |
| Protection features | Reverse polarity protection |
| Interface | PH2.0 x 2 |
| Mounting holes | M2.0 × 3 |
| Power LED | Red |
| Dimensions(W×H) | 36×24mm |
| Weight | 5g |
| Product Type | Converter |
