TTL/RS232 Converter (UC-02)
$15.50
In stockUC-01 is a TTL/USB debugging adapter that supports both half-duplex and full-duplex communication, with switchable voltage levels between 3.3V and 5.0V.
Equipped with a Type-C interface, it is designed for configuring IDs, setting parameters, and enabling communication between bus servos, PCs, and other platforms—offering broad compatibility and ease of use.
Related Products
U-Shaped Body Bracket
$50.00
4-Hole Assistant Horn
$50.00
4-Hole Main Horn
$50.00Overview
TTL/RS232 Conversion
UC-02 is a TTL/RS232 converter board with integrated half-duplex and full-duplex conversion.
5.0 V TTL Output
Supports 5.0 V TTL output.
RS232 Data Interface
Equipped with an RS232 data interface.
Broad Platform Compatibility
Suitable for communication between bus servo and other platforms, improving compatibility and ease of use.
Specification
|
Item |
Value |
|---|---|
|
Input Voltage |
6.0–15.0 V |
|
Signal Conversion |
Half-duplex to full-duplex |
|
TTL Logic Level |
5.0 V |
|
Maximum Current Capacity |
20 A |
|
Output Port |
1 serial port |
|
Data Interface |
RS232 |
|
Operating Temperature |
-10 to 60 °C |
|
Protection |
Reverse polarity protection |
|
Servo Port |
PH2.0 × 6 |
|
Mounting Holes |
M2.0 × 2 |
|
Power Indicator |
Green |
|
Dimensions |
36 × 24 mm |
|
Weight |
5 g |
Interface Definition
CAD Drawing
36 × 24 mm
Schematic
| Signal conversion | Half-duplex to full-duplex conversion |
|---|---|
| TTL level | 3.3v, 5.0v |
| Peak Current | 20A |
| UART output | 1 |
| Data interface | Type-C |
| Operating Temperature | -10 ~ 60 °C |
| Protection features | Reverse polarity protection |
| Interface | PH2.0 x 2 |
| Mounting holes | M2.0 × 3 |
| Power LED | Red |
| Dimensions(W×H) | 36×24mm |
| Weight | 5g |
| Product Type | Converter |
