Horns and Brackets - CAD Drawings and 3D Model Downloads

Tip

  • We recommend using SolidWorks 2021 or later to open the models.
  • This page only shows accessories for dual-axis servo devices. For single-axis servo accessories, please visit UART Bus Servo ｜ RS-485 Bus Servo ｜ CAN Bus Servo ｜ PWM Digital Servo.
  • Horn accessories are included at the factory. Brackets must be purchased separately.

RX6-U12H-M

RX6-U12H-M servo
Compatible servo model
RX6-U12H-M
Appearance Name Download
U-shaped body bracket - 19.6 mm U-Shaped Body Bracket (19.6 mm) PDF ｜ STEP ｜ DWGPDFSTEPDWG
U-shaped horn bracket - 16 mm U-Shaped Horn Bracket (16 mm) PDF ｜ STEP ｜ DWGPDFSTEPDWG
272 secondary horn 272 Secondary Horn PDF ｜ STEP ｜ DWGPDFSTEPDWG

RP6-U15H-M

RP6-U15H-M servo
Compatible servo model
RP6-U15H-M
Appearance Name Download
U-shaped horn bracket - 38 mm U-Shaped Horn Bracket (38 mm) PDF ｜ STEP ｜ DWGPDFSTEPDWG
U-shaped body bracket - 31 mm U-Shaped Body Bracket (31 mm) PDF ｜ STEP ｜ DWGPDFSTEPDWG
15 kg main horn 15 kg Main Horn PDF ｜ STEP ｜ DWGPDFSTEPDWG
15 kg secondary horn 15 kg Secondary Horn PDF ｜ STEP ｜ DWGPDFSTEPDWG

UART / PWM 40x40x20 (mm) Series

UART 40x40x20 mm servo series
Compatible UART servo models
RA8-U25-MRA8-U25H-MRA8-U35-MRA8-U35H-MRA8-U45-MRA8-U45H-MRX8-U26H-MRX8-U28H-MRX8-U45H-MRX8-U50H-M
PWM 40x40x20 mm servo series
Compatible PWM servo models
RA8-P25RA8-P26RA8-P35RA8-P36RP8-A45RP8-A46
Appearance Name Download
U-shaped body bracket - standard U-Shaped Body Bracket (Standard) PDF ｜ STEP ｜ DWGPDFSTEPDWG
U-shaped horn bracket - 37 mm U-Shaped Horn Bracket (37 mm) PDF ｜ STEP ｜ DWGPDFSTEPDWG
U-shaped semi-circular horn bracket - 50.7 mm U-Shaped Semi-Circular Horn Bracket (50.7 mm) PDF ｜ STEP ｜ DWGPDFSTEPDWG
8-hole main horn 8-Hole Main Horn PDF ｜ STEP ｜ DWGPDFSTEPDWG
8-hole secondary horn 8-Hole Secondary Horn PDF ｜ STEP ｜ DWGPDFSTEPDWG
4-hole main horn 4-Hole Main Horn PDF ｜ STEP ｜ DWGPDFSTEPDWG
4-hole secondary horn 4-Hole Secondary Horn PDF ｜ STEP ｜ DWGPDFSTEPDWG

Tip

  • The 8-hole horns are included at the factory. The 4-hole horns must be purchased separately.

RS-485 / CAN 40x20x48 (mm) Series

RS-485 and CAN 40x20x48 mm dual-axis servo series
Compatible dual-axis side-exit servo models
RX8-R281W-MRX8-R291W-MRX8-R501W-MRX8-R511W-MRX8-C281W-MRX8-C291W-MRX8-C501W-MRX8-C511W-M
Appearance Name Download
U-shaped body bracket - 48 mm U-Shaped Body Bracket (48 mm) PDF ｜ STEP ｜ DWGPDFSTEPDWG
U-shaped horn bracket - 56 mm U-Shaped Horn Bracket (56 mm) PDF ｜ STEP ｜ DWGPDFSTEPDWG

RX18 Series

RX18 servo series
Compatible servo models
RX18-U100H-MRX18-R100H-MRX18-R100W-MRX18-C100W-MRX18-A100-MRX18-A100H-M
Appearance Name Download
U-shaped body bracket - 51.6 mm U-Shaped Body Bracket (51.6 mm) PDF ｜ STEP ｜ DWGPDFSTEPDWG
U-shaped horn bracket - 59.6 mm U-Shaped Horn Bracket (59.6 mm) PDF ｜ STEP ｜ DWGPDFSTEPDWG
8-hole main horn 8-Hole Main Horn PDF ｜ STEP ｜ DWGPDFSTEPDWG
8-hole secondary horn 8-Hole Secondary Horn PDF ｜ STEP ｜ DWGPDFSTEPDWG

Tip

  • Robot brackets and Pan-Tilt brackets are open-source 3D-print parts and are not sold.

Robot Brackets

Appearance Name Download
U-shaped connector U-Shaped Connector PDF ｜ STEP ｜ DWGPDFSTEPDWG
Cross connector Cross Connector PDF ｜ STEP ｜ DWGPDFSTEPDWG

Pan-Tilt Brackets

Appearance Name Download
OpenMV and laser pointer combo bracket OpenMV and Laser Pointer Combo Bracket PDF ｜ STEP ｜ DWGPDFSTEPDWG
